Docker registries and Kubernetes
To deploy a container on k8s you will need your container image available on a publicly available container registry server.
Below we will show you how to use either Github’s GHCR service or Gitlab’s Container Registry service to store and deploy container’s to any Kubernetes cluster.
What is a container registry?
A container registry, sometimes called a Docker registry, is a service that holds container images, such as those made with docker
and other tools, and allows k8s to pull them with a well known API.
The well known API is now referred to as the OCI Distribution Specification. It was previously referred to simply as Docker Registry, with the API being called Docker Registry HTTP API v2. The definitive Registry implementation is now called simply Distribution - and it has been donated to CNCF. The implementation is available on github: Distribution
Regsitry Services
Running Distribution on your own requires setup, is another service you must maintain, and involves various security implementations. There are a variety of products, many of which you may already have at your disposal, that implement the OCI Distribution API - aka. provide a container registry service.
- Github ghcr.io (Github Container Registry)
- Gitlab Container Registry
- AWS ECS
- Google Cloud Artifact Registry (as of May 15, 2023 Google Cloud Container Registry is deprecated)
- Quay.io
- Docker Hub
If hosting your own OCI Distribution service is required - such as in an on-premise or isolated installation, then look at these projects:
- Harbor is a well-known, actively developed, fully featured container registry
- Neuxs is another open-source product that has a commercially available option as well.
- The Distribtution service itself from CNCF. It is a bit more complicated and less feature-rich than the ones above.
Choosing a service
Chances are you / your organization already pay for Github or Gitlab. For this reason, using their services is worth a look since they will effectively be free. Also, GHCR is free for public images.
If you deploy on AWS or Google Cloud already, look at their corresponding container services as well. These services can make secrets management on their platforms easier, since any container pull done by k8s on their platform will automatically authenticate with their service. That being said their services are not free. Additionally pulling from their container services from the outside can be more complicated. In large organizations, the complicated permissions on these services can take even more time to iron out.
Recommendation: Just use Github or Gitlab registries
To make developer and dev ops flow simple, and not have to involve dev ops too significantly in the developer workflow - we generally recommend using Github or Gitlab services.
Tutorial: Push & Deploy a container from Github GHCR
In this example, we are going to build a container and push it to Github GHCR. Then we will deploy it on k8s.
In our example we are going to reference a trivial Go service: trivial-golang-k8s-deployment but any container image will apply.
Build and tag your container image
Build your docker image and tag it. Replace trivial-golang-k8s-deployment
with whatever you will call your container image.
docker build --tag trivial-golang-k8s-deployment .
Push to GHCR
First you will need to login to GHCR from docker.
As noted by Github in their docs, you must use a Personal Access Token (classic) in order to login to GHCR. You can generate a token by going here once logged into Github:
https://github.com/settings/tokens/new
Check the write:packages capability for your token. This will automatically select the repo capbabilities (and all sub capabilities)
Once generated, store your token somewhere secure. Here we always use a password manager like KeePassXC.
Login to GHCR: Docker login with token
Login to ghcr.io
docker login ghcr.io
Username: The email address you use for Github
Password: The token you generated above
Look for…
Login Succeeded
Tag & Push
Now we need to push our image to ghcr.io.
A word on registry paths with Github:
By convention, you should follow this pattern:
ghcr.io/NAMESPACE/IMAGE_NAME:TAG
Where NAMESPACE
is the org or personal account. So in our example repo at github.com/IzumaNetworks/trivial-golang-k8s-deployment NAMESPACE
is izumanetworks
(capitals are not allowed)
The IMAGE_NAME:TAG
can be anything. However, by convention, the IMAGE_NAME
would typically match or be relatable to the repo name. TAG
is always the version number or a development status such as latest
or dev
or alpha
In order to push our image we need to tag it using a path to ghcr.io. Above, using our example repo, we built and tagged it as trivial-golang-k8s-deployment
. It is currently stored in the Docker image cache locally.
docker images
Let’s tag it and then push to ghcr.io:
docker tag trivial-golang-k8s-deployment ghcr.io/izumanetworks/trivial-golang-k8s-deployment:latest
docker push ghcr.io/izumanetworks/trivial-golang-k8s-deployment:latest
Deployment on K8s from ghcr.io
K8s needs a secret stored in a specific way in order to pull from a private registry. If your image is publicly available, you can pull it without a secret.
Creating a read-only K8s token for GHCR
While we could use the same token above for pulling the repo, its more secure to use a new token which only has read access to the registry.
Follow similar procedures as above…
- Go to https://github.com/settings/tokens/new
- Click read:packages (you only need this)
- Save the token somewhere secure
Create a k8s secret from the token
There are a number of ways to create registry tokens - look at the k8s docs for all the options.
A simple way is to run:
kubectl create secret docker-registry regcred --docker-server=ghcr.io --docker-username=GITHUB_EMAIL --docker-password=TOKEN --docker-email=GITHUB_EMAIL
where TOKEN
is the read-only token we just made and GITHUB_EMAIL
is the email you use to sign into Github:
Output:
secret/regcred created
Success. Now let’s check the secret.
Verify our registry secret: Peek at dockerconfigjson
The command above creates a k8s secret of type: kubernetes.io/dockerconfigjson
FYI: the secret is called dockerconfigjson
because normally the docker
stores credentials in ~/.docker/config.json
A special base64 encoded of .dockerconfigjson
- is in the secret. This contains the auth information for the registry
kubectl get secret regcred --output=yaml
Outputs something like this:
apiVersion: v1
data:
.dockerconfigjson: eyJasdasdasdxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx...=
kind: Secret
metadata:
creationTimestamp: "2023-11-29T05:28:23Z"
name: regcred
namespace: default
resourceVersion: "5422565"
uid: fcfbde08-9699-4e9e-b13a-d033e2b37bc1
type: kubernetes.io/dockerconfigjson
The value in .dockerconfigjson
is a base64 encoded. Let’s look at it:
kubectl get secret regcred --output="jsonpath={.data.\.dockerconfigjson}" | base64 --decode
will yield a result similar to:
{"auths":{"ghcr.io":{"username":"[email protected]","password":"ghp_xxxxxxxxxxxxxxxxxxx","email":"[email protected]","auth":"sadasjdhXsdskdjASZQkjsadjksjdaskdjaksdjaksdjaskdjaskdj=="}}}%
Verify your fields look correct.
Create a Deployment using our registry secret
Create a new YAML file - deployment.yaml
(or use the one in our example repo). As before - trivial-golang-k8s-deployment
could be replaced with your own pod name.
apiVersion: v1
kind: Pod
metadata:
name: trivial-golang-k8s-deployment
labels:
app: trivial-golang-k8s-deployment
spec:
containers:
- name: trivial-golang-k8s-deployment
image: ghcr.io/izumanetworks/trivial-golang-k8s-deployment:latest
imagePullPolicy: Always
ports:
- containerPort: 8080
imagePullSecrets:
- name: regcred
Notice the imagePullSecrets
uses the regcred
secret. Also - we use imagePullPolicy: Always
to ensure in our testing we actually do a pull.
Deploy it:
kubectl apply -f deployment.yaml
and then…
kubectl describe pod trivial-golang-k8s-deployment
should reveal the pull successfully happening.
Output:
...
Normal Scheduled 8s default-scheduler Successfully assigned default/trivial-golang-k8s-deployment to gke-test-cluster-default-pool-da432508-ftsl
Normal Pulling 8s kubelet Pulling image "ghcr.io/izumanetworks/trivial-golang-k8s-deployment:latest"
Normal Pulled 7s kubelet Successfully pulled image "ghcr.io/izumanetworks/trivial-golang-k8s-deployment:latest" in 327.13398ms (327.148349ms including waiting)
Normal Created 7s kubelet Created container trivial-golang-k8s-deployment
Normal Started 7s kubelet Started container trivial-golang-k8s-deployment
There it is. You can now pull images from GHCR into your k8s cluster.
While it may not be plainly obvious, regcred
is not a special name. The registry credential secrets are just any other secret object. You can name your registry secrets anything, and you can use multiple secrets if you have different secure registries.
Also bear in mind the same rules apply as for other secrets. Secrets aren’t shared across namespaces for instance.
Tutorial: Push & Deploy a container From Gitlab Container Registry
In this example, we are going to build a container and push it to Gitlab Container Registry. Then we will deploy it on k8s. The process is very similar to Github above.
Push to Gitlab
You will need to login to Gitlab Container Regsitry from docker.
As noted by Gitlab in their docs, you can use a Personal Access Token, Deploy Token and a few other methods for login. We are going to just use a Personal Access Token:
Go to https://gitlab.com/-/profile/personal_access_tokens
Click Add New Token
Name your token, and choose read_registry and write_registry for permissions. Store the token somewhere secure.
Login to Gitlab Container Registry
docker login registry.gitlab.com
Username: The username you have in Gitlab (if you click your profile pic you will see @username)
Password: The token you generated above
Look for…
Login Succeeded
While the docker login
command offers the -u
and -p
options - you should never use these. This will put your token on the command history of your shell. Best practice is to login with a method that does not make a record of the password (token).
There are a number of ways to login to an OCI Registry programmatically. For instance the --password-stdin
option.
Example:
echo $MYTOKEN | docker login registry.gitlab.com -u myusername --password-stdin
Tag & Push
Like Github ghcr.io, Gitlab’s registry has a convention for image paths:
registry.gitlab.com/GROUP/PROJECT/IMAGE_NAME:TAG
Where GROUP
is the Gitlab group the project is in. So for our example, the repo https://gitlab.com/izumanet/trivial-golang-k8s-deployment
will be used - izumanet
is the group. Project is trivial-golang-k8s-deployment
The IMAGE_NAME
can be anything. TAG
is typically the version number or a development status such as latest
or dev
or alpha
We need to tag our container image for Gitlab. Using our example repo, we built above and tagged as trivial-golang-k8s-deployment
:
docker tag trivial-golang-k8s-deployment registry.gitlab.com/izumanet/trivial-golang-k8s-deployment/app:latest
docker push registry.gitlab.com/izumanet/trivial-golang-k8s-deployment/app:latest
Because Gitlab requires the project name to be in the path, I just chose to call the image app
to simplify things. You could call it whatever you want.
Deployment on K8s from Gitlab Registry
Now let’s create a k8s secret for authentication to Gitlab’s registry. Process is the same as Github.
Creating a read-only K8s token for deployment from Gitlab
We could use the same token above for pulling the repo, but let’s create a read-only token for security reasons. Other tokens like deploy tokens are an option on Gitlab.
Follow similar procedures as above…
- Go to https://gitlab.com/-/profile/personal_access_tokens - Click Add New Token
- Click read_registry (you only need this)
- Save the token somewhere secure
Create a k8s secret from the token
We will follow the same procedures we did for Github - we are going to call this secret regcredgitlab
:
kubectl create secret docker-registry regcredgitlab --docker-server=registry.gitlab.com --docker-username=GITLAB_USERNAME --docker-password=TOKEN --docker-email=GITLAB_EMAIL
where TOKEN
is the read-only token we just made and GITHUB_EMAIL
is the email you use to sign into Github:
Output:
secret/regcredgitlab created
Success.
The k8s official examples require you to type your token on the command line. Here is how to enter your token without it going into the command history:
kubectl create secret docker-registry regcredgitlab --docker-server=registry.gitlab.com --docker-username=GITLAB_USERNAME --docker-password=`read -r pass; echo $pass` --docker-email=GITLAB_EMAIL
Type in your token right afterwards then ENTER.
Some versions of read
support the -s
switch - this will also prevent what you type from echoing to the terminal.
If you want to verify the secret you can use the same procedures as above for Github.
Create a Deployment using our secret for Gitlab
The process for deployment mirrors the process with Github. Notice our imagePullScrets
is now regcredgitlab
apiVersion: v1
kind: Pod
metadata:
name: trivial-golang-k8s-deployment
labels:
app: trivial-golang-k8s-deployment
spec:
containers:
- name: trivial-golang-k8s-deployment
image: registry.gitlab.com/izumanet/trivial-golang-k8s-deployment/app:latest
imagePullPolicy: Always
ports:
- containerPort: 8080
imagePullSecrets:
- name: regcredgitlab
Again, we use imagePullPolicy: Always
to ensure in our testing we actually do a pull.
Deploy it:
kubectl apply -f deployment-gitlab.yaml
and then…
kubectl describe pod trivial-golang-k8s-deployment
should reveal the pull successfully happening.
Output:
...
Normal Scheduled 6s default-scheduler Successfully assigned default/trivial-golang-k8s-deployment to gke-test-cluster-default-pool-da432508-ftsl
Normal Pulling 6s kubelet Pulling image "registry.gitlab.com/izumanet/trivial-golang-k8s-deployment/app:latest"
Normal Pulled 5s kubelet Successfully pulled image "registry.gitlab.com/izumanet/trivial-golang-k8s-deployment/app:latest" in 450.879137ms (450.901273ms including waiting)
Normal Created 5s kubelet Created container trivial-golang-k8s-deployment
Normal Started 5s kubelet Started container trivial-golang-k8s-deployment
You can now pull images from Gitlab into your k8s cluster.
General Troubleshooting
Running kubectl get pods
after deployment should reveal a Running
pod. Instead if you see a ErrImgPull
or ImagePullBackOff
there is problem with your secret or image path.
Starting by running:
kubectl describe pod trivial-golang-k8s-deployment
Output might look like:
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Normal Scheduled 5s default-scheduler Successfully assigned default/trivial-golang-k8s-deployment to gke-test-cluster-default-pool-da432508-ftsl
Normal Pulling 4s kubelet Pulling image "registry.gitlab.com/izumanet/trivial-golang-k8s-deployment/app:latest"
Warning Failed 4s kubelet Failed to pull image "registry.gitlab.com/izumanet/trivial-golang-k8s-deployment/app:latest": rpc error: code = Unknown desc = failed to pull and unpack image "registry.gitlab.com/izumanet/trivial-golang-k8s-deployment/app:latest": failed to resolve reference "registry.gitlab.com/izumanet/trivial-golang-k8s-deployment/app:latest": failed to authorize: failed to fetch oauth token: unexpected status from GET request to https://gitlab.com/jwt/auth?scope=repository%3Aizumanet%2Ftrivial-golang-k8s-deployment%2Fapp%3Apull&service=container_registry: 401 Unauthorized
Warning Failed 4s kubelet Error: ErrImagePull
Normal BackOff 3s kubelet Back-off pulling image "registry.gitlab.com/izumanet/trivial-golang-k8s-deployment/app:latest"
Warning Failed 3s kubelet Error: ImagePullBackOff
Notice the 401 Unauthorized
- definitely a credential problem or a bad image path of some kind.
Verify your token works and your image path is correct
If your secret in k8s is not working, then test the token outside k8s as first step:
- use
docker login
with the same secret you want K8s to use. - If you have already logged into a registry, you may need to remove the cached credential: remove the appropriate key / value pair in the
~/.docker/config.json
or the equivalent file on your system. - If
docker login
is successful, try doing a pull of the image. - If all this works, then something is wrong with your K8s secret config itself, not the token.
A failed docker login will usually reveal your token or path issue:
Error response from daemon: Get "https://registry.gitlab.com/v2/": unauthorized: HTTP Basic: Access denied. The provided password or token is incorrect or your account has 2FA enabled and you must use a personal access token instead of a password. See https://gitlab.com/help/user/profile/account/two_factor_authentication#troubleshooting
CI / CD considerations
The above examples are good for deployment tasks on almost any K8s cluster, including Izuma Networks own Izuma Edge nodes.
However, if you are developing a CI/CD pipeline, you will want to use Github Actions or Gitlab Pipelines. These can build, upload your package to the registry, and trigger a k8s deployment all automatically if designed correctly.
For a later series of posts…
